The list displays.
8. To allow the WiFi-enabled computer or mobile device you’re currently using to
continue to access the Internet, select the check box next to your computer or device,
and click the Allow button.
9. Click the Apply button.
Your settings are saved.
Use keywords to block Internet sites
You can use keywords to block certain Internet sites from your network. You can use
blocking all the time or based on a schedule.
Note: Keyword blocking only works for website URLs that begin with http:// only. It
does not work for URLs that begin with https://.
To block Internet sites:
1.
Launch a web browser from a computer or mobile device that is connected to the
router network.
2.
Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Security > Block Sites.
The Block Sites page displays.
5. Select a keyword blocking option:
Per Schedule. Turn on keyword blocking according to a schedule that you set.
For more information, see Schedule when to block Internet sites and services on
page 52.
Always. Turn on keyword blocking all the time, independent of the Schedule
page.
6.
In the Type keyword or domain name here field, enter a keyword or domain that
you want to block.
User Manual48Control Access to the Internet
Nighthawk AX8 8-Stream Tri-Band WiFi 6 Router

Table of Contents

Other manuals for NETGEAR Nighthawk AX8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Nighthawk AX8 and is the answer not in the manual?

NETGEAR Nighthawk AX8 Specifications

General IconGeneral
Modulation1024-QAM
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standardsWi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth160 MHz
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN data transfer rate (max)6000 Mbit/s
WLAN data transfer rate (first band)1200 Mbit/s
WLAN data transfer rate (second band)4800 Mbit/s
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Memory card slot(s)No
Ethernet LAN (RJ-45) ports5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
WAN connection typeRJ-45
Processor cores4
Processor frequency1800 MHz
Electromagnetic compatibilityFCC 15 B EN 55022 (CISPR 22), B C-Tick N10947
Security algorithms128-bit AES, WPA, WPA2, WPA2-PSK
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, Power, WAN
Output current3.16 A
Output voltage19 V
Power source typeAC
AC input frequency50 - 60 Hz
Package depth307 mm
Package width238 mm
Package height129 mm
Package weight2380 g
Number of products included1 pc(s)
Cables includedLAN (RJ-45)
Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Routing protocolsRIP-1, RIP-2
Data link protocolsTCP/IP, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, SMB
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 90 %
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth202 mm
Width305 mm
Height161 mm
Weight1281 g
