Specify Network Settings
68
Orbi High-Performance AC3000 Tri-band WiFi System
3. Enter the router user name and password.
The user name is admin.
The default password is password. The user name and
password are case-sensitive.
The BASIC Home page displays.
4. Select ADV
ANCED > Setup > LAN Setup.
5. Select the radio button next to the reserved address.
6. Click the Delete button.
The address is removed.
Custom Static Routes
Typically, you do not need to add static routes unless you use multiple routers or multiple IP
subnets on your network.
As an example of when a static route is needed, consider the following case:
• Y
our main Internet access is through a cable modem to an ISP.
• Y
our home network includes an ISDN router for connecting to the company where you
are employed. This router’s address on your LAN is 192.168.1.100.
• Y
our company’s network address is 134.177.0.0.
When you set up your router, two implicit static routes were created. A default route was
created with your ISP as the gateway
, and a second static route was created to your local
network for all 192.168.1.x addresses. With this configuration, if you try to access a device on
the 134.177.0.0 network, your router forwards your request to the ISP. The ISP forwards your
request to the company where you are employed, and the company firewall is likely to deny
the request.
In this case you must define a static route, telling your router to access 134.177.0.0 through
the ISDN router at 192.168.1.100. Here is an example:
