Overview
8
Orbi High-Performance AC3000 Tri-band WiFi System
Orbi Router and Satellite Overview
The top of the Orbi router is blue. The top of the Orbi satellite is white.
Router Satellite
1
2
5
6
1
8
8
2
6
577344
Figure 1. Orbi router and satellite, front and back views
1. Ring LED (not shown in image) 5. USB port
2. Sync button (also used for WPS connection) 6. Power On/Off button and Power LED
3. Internet port (the Orbi satellite does not include
an Internet port)
7. DC Power connector
4. Ethernet ports 8. Reset button
