NETGEAR ProSafe FS750T2 Specifications

Technical Specifications
• Network Protocol and Standards
Compatibility:
-
IEEE 802.3 10BASE-T
- IEEE 802.3u 100BASE-TX
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3x full-duplex flow control
• Interfaces
-
48 10/100 Mbps auto sensing Fast Ethernet
switching ports
- 2 built-in RJ-45 G
igabit Ethernet ports for
10/100/1000 Mbps connectivity
- 2 SFP slots for fiber Gigabit Ethernet modules
• Port Functions
-
Auto-sensing and auto-negotiating capabilities
for all ports
- Auto Uplink™ on all ports to make the
right connection
• Administrative Switch Management
-
IEEE 802.1Q Static VLAN (Up to 64)
- Port-based VLAN (Up to 50)
- IEEE 802.1p Class of Service (CoS)
- Port-based QoS
- IEEE802.3ad (manual) Link Aggregation
- IEEE 802.1D Spanning Tree Protocol***
- RFC 1157 SNMP v1***
- RFC 1213 MIB II***
- RFC 1643 Ethernet Interface MIB***
- RFC 1493 Bridge MIB***
- RFC 2131 DHCP client
- Private Enterprise MIB***
- Port Mirroring Support
- Web-based configuration
- Configuration Backup/Restore
- Password Access Control
- F
irmwar
e upgradeable
• Active Flow Control
-
H
alf-duplex back-pressure control
- Full-duplex IEEE 802.3x pause frame flow control
• Performance Specifications
-
Forwarding modes: Store-and-forward
- Bandwidth: 13.6 Gbps
- N
etwor
k latency:
Less than 20 micr
oseconds for
64-b
yte frames in store-and-forward mode for100
Mbps to 100 Mbps transmission
- Buffer memory: 128 KB
- Address database size: 8,000 media access control
(MA
C) addr
esses per system
- Addressing: 48-bit MAC address
- Mean Time Between Failure (MTBF): 59,880
hours (~ 6.8 years)
• LEDs
-
Unit: Power
- Per port: Link, Activity, Speed
NETGEAR Related Products
-
GA311 32-bit Gigabit
PCI Adapter
- GA511 Gigabit PC Card Adapter
- GS105 5-port Gigabit Switch
- GS108 8-por
t Gigabit Switch
- GS116 16-port Gigabit Switch
- GS516T 16-port Gigabit Switch
- GS524T 24-port Gigabit Switch
- FS726T 24-port 10/100 Smart
Switch with 2 Gigabit ports
- GS716T 16-port Gigabit
Smart Switch
- GS724T 24-port Gigabit
Smart Switch
- GS748T 48-port Gigabit
Smart Switch
- NMS100 Network
Management System
- P3L21 Layer 2 Support Pack
– 1 year
- P3L23 Layer 2 Support Pack
– 3 years
FS750T2 ProSafe 48-port 10/100
Smart Switch with 2 Gigabit Ports
• P
ower Supply
-
Power Consumption: 21 W maximum
- 100-240VAC/50-60 Hz universal input
• Physical Specifications
-
Dimensions (H x W x D): 1.7 x 17.8 x 8.1 in.
(43 x 440 x 205 mm)
- Weight: 7.0 lbs (3.2 kg)
• Environmental Specifications
-
Operating temperature: 32 to 104° F (0 to 40° C)
- Storage temperature: -4 to 158° F (-20 to 70° C)
- Operating humidity: 90% maximum relative humidity,
non-condensing
- Storage humidity: 95% maximum relative humidity,
non-condensing
- Operating altitude: 10,000 ft (3,000 m) maximum
- Storage altitude: 10,000 ft (3,000 m) maximum
• Electromagnetic Compliance
-
CE mark, commercial
- FCC Part 15 Class A
- VCCI Class A
- EN 55022 (CISPR 22),
- EN 55024 (CISPR 24)
- C-Tick
• Safety
- CE mark, commercial
- CUL 60950 (Listed)/ EN60950
(Low Voltage Directive)
• Warranty
-
Switch: NETGEAR 5-year warranty
System Requirements
-
Category 5 network cables
- N
etwor
k car
d for each PC
- Network software (e.g., Windows
®
)
Package Contents
-
FS750T2 P
r
oS
afe 48-por
t S
mart Switch with
2 G
igabit Ports
- Rubber footpads
- Power cord
- Rack-mount kit
- S
mart Switch resource CD
- Smart Switch installation guide
- Warranty/Support information card
Modules
-
P
r
oSafe AGM731F 1000BASE-SX SFP GBIC:
Module with LC connectors for 50um or 62.5um
multi-mode fiber cable
- ProSafe AGM732F Fiber 1000BASE-LX SFP GBIC:
Module with LC connectors for 9um single-mode
fiber cable
4500 Great America Parkway
Santa Clara, CA 95054 USA
Phone: 1-888-NETGEAR (638-4327)
E-mail: info@NETGEAR.com
www.NETGEAR.com
©2005 NETGEAR, Inc. NETGEAR®, the
Netgear Logo, Auto Uplink, ProSafe, and
Everybody's connecting are trademarks or
registered trademarks of Netgear, Inc. in
the United States and/or other countries.
Microsoft, Windows, Windows Media, and
the Windows logo are trademarks, or
registered trademarks of Microsoft
Corporation in the United States and/or
other countries. Other brand and product
names are trademarks or registered
trademarks of their respective holders.
Information is subject to change
without notice. All rights reserved.
* Free basic installation support provided
for 90 days from date of purchase.
Advanced product features and
configurations are not included in free
basic installation support; optional
premium support available.
D-FS750T2-1
