Figure 10. Smart Connect
For Smart Connect to work, both 5 GHz radio bands must use the same WiFi network name (SSID) and network
key (password).That means that when you connect to the router with WiFi, you see only one 5 GHz SSID that
connects to both 5 GHz radio bands.
If you enable Smart Connect and the SSID and passwords for both 5 GHz radio bands do
not match, the WiFi settings for 5 GHz radio 1 overwrite the WiFi settings for 5 GHz radio 2.
Note
Enable or Disable Smart Connect
To enable or disable Smart Connect:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is password.The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select Wireless.
Tri-Band WiFi Connections
63
Nighthawk X8 AC5000 Tri-Band WiFi Router
