16 Manually Installing Your Router
7. Connect any additional wired PCs to your router by inserting an Ethernet cable from a PC into
one of the three remaining LAN ports.
8. Review that your network is now set up (as shown in Figure 9); you are ready to start your
network.
9. Start your network in the correct sequence, as described below.
To start your network:
1.
Plug in and turn on the cable or DSL modem. Wait 2 minutes.
2. Plug the end of the power adapter’s cord into the wall or a power strip, and into the power
adapter outlet of your wireless router (F), as shown in Figure 10. Wait 1 minute.
Figure 9
Failure to start or restart your network in the correct sequence could prevent you
from accessing the Internet.
Figure 10
