8.
To add a service or application that is not in the menu, select User Defined, and do
the following:
a.
If you know that the application uses either TCP or UDP, select the appropriate
protocol. Otherwise, select TCP/UDP (both).
b. Enter the starting port and ending port numbers.
If the service uses a single port number, enter that number in both fields. To find
out which port numbers the service or application uses, you can contact the
publisher of the application, ask user groups or newsgroups, or search on the
Internet.
9.
Select a filtering option:
Only This IP Address. Block services for a single computer.
IP Address Range. Block services for a range of computers with consecutive IP
addresses on your network.
All lP Addresses. Block services for all computers on your network.
10. Click the Add button.
Your settings are saved.
Prevent blocking on a trusted computer
You can exempt one trusted computer from blocking. The computer that you exempt
must be assigned a fixed IP address. You can use the reserved IP address feature to
specify the IP address. See Manage reserved LAN IP addresses on page 58.
To specify a trusted computer:
1.
Launch a web browser from a computer or mobile device that is connected to the
router network.
2.
Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Security > Block Sites.
The Block Sites page displays.
5. Scroll down and select the Allow trusted IP address to visit blocked sites check
box.
User Manual46Control Access to the Internet
4-Stream AX1800 WiFi 6 Router

Table of Contents

Other manuals for NETGEAR RAX10

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR RAX10 and is the answer not in the manual?

NETGEAR RAX10 Specifications

General IconGeneral
WiFi TechnologyWiFi 6 (802.11ax)
WiFi PerformanceAX1800
Wireless SpeedUp to 1.8Gbps
Antenna4 External Antennas
BeamformingYes
MU-MIMOYes
OFDMAYes
Maximum SpeedUp to 1.8Gbps
Number of Ethernet Ports5
Ethernet Ports4 x Gigabit Ethernet
SecurityWPA3
Memory128MB Flash and 256MB RAM
WiFi BandDual-band (2.4 GHz & 5 GHz)
