NETGEAR RAX200 User Manual

Top panel LEDs and buttons
The status LEDs and two buttons are located on the top panel of the router.
Figure 2. Top view
Table 1. LED descriptions
DescriptionLED and Button
Solid white. The router is ready.
Blinking white. The router is not ready, firmware is upgrading, or the Reset
button was pressed.
Off. Power is not supplied to the router.
Power LED
Solid white. The Internet connection is ready.
Blinking white. The port is sending or receiving traffic.
Off. No Ethernet cable is connected between the router and the modem.
Internet LED
User Manual11Hardware Setup
Nighthawk Tri-Band AX12 12-Stream AX WiFi Router

NETGEAR RAX200 Specifications

General

USB Ports	2x USB 3.0
Beamforming	Yes
MU-MIMO	Yes
OFDMA	Yes
WiFi Technology	802.11ax
Processor	1.8GHz Quad-Core Processor
Ethernet Ports	1x 2.5G WAN, 4x 1G LAN
Security	WPA3
Memory	512MB NAND flash, 1GB RAM
Antenna	8x High-Performance Antennas
