Disk Trays
The following figure shows the features of the disk tray.
7
62
3
4
1
5
Figure 4. Disk tray
1. Disk tray
2. Disk tray release latch
3. Recessed disk tray handle lock
4. Disk tray handle
5. Disk screw holes
6. Mounting bracket
7. Mounting bracket lock
IMPORTANT:
To maintain adequate airflow, make sure that all disk trays remain
in the drive bays, even if no disk is installed in the tray.
