Reference Guide for the Model RT311 and RT314 Internet Access Gateway Routers
Configuring Filters 10-3
3.
When you have finished filling in the Edit Comments field, press [Enter] at the Press
ENTER to Confirm... prompt to confirm your selections, or press [Esc] at any time to
cancel your selections.
The new information is displayed in the read-only section of Menu 21 - Filter Set
Configuration.
4.
Press [Enter] to display Menu 21.1 - Filter Rules Summary (Figure 10-2).
Figure 10-2. Menu 21.1 - Filter Rules Summary
The information in this menu is read-only; the parameters of each rule that you configured for that
set are displayed.
Table 10-1 lists and describes the abbreviations used in Menu 21.1 - Filter Rules Summary.
Table 10-1. Abbreviations Used in Menu 21.1 - Filter Rules Summary
Abbreviation Description
# Refers to the filter rule number (1–6).
A Refers to Active. Y means the filter rule is active, and N means the filter rule is
inactive.
Type Refers to the type of filter rule and can display GEN for generic or IP for TCP/IP.
Filter Rules The filter rule parameters are displayed here.
M Refers to More. Y means there are more rules to check. N means there are no rules to
check.
Menu 21.3 - Filter Rules Summary
# A Type Filter Rules M m n
- - ---- --------------------------------------------------------------- - - -
1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=137 N D N
2 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=138 N D N
3 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=139 N D N
4 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=137 N D N
5 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=138 N D N
6 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=139 N D F
Enter Filter Rule Number (1-6) to Configure:
