NETGEAR SC101 Reference Manual

Reference Manual for the NETGEAR Storage Central SC101
3-4
v1.0, September 2005
3. Connect the hard disk cables.
a. Align and insert the hard disk power cable into the D-shaped power socket.
b. Align the key of the hard disk data cable with the slot on the data cable socket and insert
the cable. Neatly tuck the cables in so that they will not interfere with attaching the cover.
Figure 3-6
4. Attach the front cover.
a. Align the cover with
the unit.
b. Using a screwdriver or
coin to hold the spring
loaded cover lock
open, attach the cover,
then release the lock.
Figure 3-7
Power Cable
Data Cable
Data Cable Key
