By default, the Clients button is selected.
5.
To view traffic information, do the following:
a.
Click the Traffic button.
The graph shows the information for Ethernet (wired LAN) traffic, total WiFi traffic,
WiFi traffic for the 2.4 GHz radio, and WiFi traffic for each 5 GHz radio.
b.
To view more information, point to a node on one of the lines on the graph.
6.
To view channel utilization, do the following:
a. Click the Channel Utilization button.
The graph shows the channel utilization for the 2.4 GHz radio.
b.
To view the channel utilization for a 5 GHz radio, click the 5 GHz Low or 5 GHz
High button.
c.
To view more information, point to a bar.
7.
To change the period over which information is filtered and displayed, select the
number of recent hours from the menu to the right of the buttons.
