NETGEAR WN3100RP Installation

13
Find the Best Location
If the WiFi signal is weak, the first time you join the extender network, an
arrow LED blinks for two minutes. If this happens, adjust the position of
the extender.
• If the Router Arrow LED blinks, move the extender closer to
the router.
• If the Client Arrow LED blinks, move the computer or WiFi
device closer to the extender.
If no arrow LEDs are lit, the extender is in a good location.

NETGEAR WN3100RP Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA2-PSK, WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	32.5 mm
Width	55 mm
Height	114 mm
Weight	175 g
