2
Getting to Know Your Router
Most connectors are on the rear panel.
The following figure shows the front panel.
WAN
Reset
Power On/Off
Power connector
(Internet)
port
LAN ports 1–4
USB ports
WPS button
WiFi On/Off button
Power LED
Internet LED
2.4 GHz LED
5 GHz LED
Ethernet (LAN) LEDS
USB LEDs
WPS LED
