4
5 GHz
• Solid blue. The wireless radio is operating.
• Blinking. The router is in WPS mode.
• Off. The wireless radios is off.
LAN ports 1–4
• Solid green. The LAN port has detected a
1,000 Mbps link with an attached device.
• Solid amber. The LAN port detected a
10/100 Mbps link with an attached device.
• Off. No link is detected on this port.
USB
1 and USB 2 • Solid green. The router has accepted the USB
device. The USB device is ready to be used.
• Blinking green. The USB device is in use.
• Off. No USB device is connected, or the Safely
Remove Hardware button has been clicked, and it
is now safe to remove the attached USB device.
Table 1. LEDs (continued)
LED Description
