NETGEAR WNR2000V3 User Manual

Manually Installing Your Router 14
5. Locate the Ethernet cable that came with your NETGEAR product. Securely insert one end of
the Ethernet cable into your modem (C) and the other end into the Internet port of the wireless
router (D). (The cable and the Internet port label are color coded.)
6. Locate the cable (A) that is still attached to your computer (see step 4). Securely insert that
cable into a port on the router, such as port 4 (E), as shown in Figure 9.
7. Connect any additional wired PCs to your router by inserting an Ethernet cable from a PC into
one of the three remaining LAN ports.
Figure 8
Figure 9
Internet
Internet
1
2
3
4
C
D
1
2
3
4
Internet
A
E

NETGEAR WNR2000V3 Specifications

General

Frequency Band	2.4 GHz
Wireless Speed	300 Mbps
LAN Ports	4 x 10/100 Mbps
WAN Port	1 x 10/100 Mbps
Antenna	2 internal antennas
Wireless Standard	802.11n
Security	WPA, WPA2, WEP
Dimensions	177 x 130 x 35 mm
Power Supply	12V/1A
Weight	270 g (0.6 lb)
