N300 Wireless Router with USB WNR2200 User Manual
Safeguarding Your Network 2-8
v1.0, September 2010
Configuring WEP Wireless Security
To configure WEP data encryption:
1. Log in to the wireless router at its default LAN address of http://www.routerlogin.net with
its default user name of admin, and default password of password, or using whatever
password and LAN address you have chosen for the wireless router.
• WPA/WPA2 Enterprise. Allow computers configured with either
WPA-PSK or WPA2-PSK security to connect to the wireless
router. When you select this option, this additional area appears
on your screen:
Security Options (WPA/WPA2 Enterprise)
• WPA Mode. Select the WPA Mode from the drop-down
list (WPA [TKIP], WPA2 [AES], or WPA [TKIP + WPA2
[AES]).
• RADIUS server IP Address. Enter the IP address of the
RADIUS server.
• RADIUS server Port. The RADIUS server port number is
listed in this field.
• RADIUS server Shared Secret. Enter the Shared
Secret.
Note: WEP security is only available when you select Up to 54 Mbps on the Wireless
Settings screen.
Note: If you use a wireless computer to configure wireless security settings, you will be
disconnected when you click Apply. Reconfigure your wireless computer to match
the new settings, or access the wireless router from a wired computer to make
further changes.
Table 2-1. Wireless Settings (continued)
Settings Description
