N300 Wireless Router with USB WNR2200 User Manual
Customizing Your Network Settings 5-2
v1.0, September 2010
To configure LAN IP settings, log in to the router, and under the Advanced heading, select LAN
Setup. The following screen displays:
If you make changes you must click Apply in order for the changes to take effect.
The LAN Setup fields are explained in the following table.
Figure 5-1
Note: If you change the LAN IP address of the router while connected through the
browser, you will be disconnected. You must then open a new connection to the
new IP address and log in again.
Table 5-1. LAN Setup
Settings Description
Device Name A descriptive name for the router, which will be shown in the
Network on Windows Vista and the Network Explorer on all
Windows systems. The Device Name field cannot be blank.
