Netis WF2322 User Manual

WISP Mode :
Select target network and Connection Type.
1. Click “AP Scan” button to select your target network and click “Connect” button.
2. Type in the wireless security info of the target network.
3. Select connection type. (Please refer to “Internet Settings” →“AP Router Mode”)
6
Note: The DHCP Server will be disabled after switching to “AP” mode successfully, so you will have
to set a static IP address for your PC first if you need to login to the web-based management page again.
3.4 The web management page will display after login successfully. Select the language as you need
on the top box, default is in English.
Wireless Settings
Setup a wireless network name in “SSID” box, it is recommended to use WPA-PSK/WPA2-PSK for
“Security” and set a wireless network key in the “Password” box, then click “Save” button.
3.5 When you completed the configuration,please remember to change the settings on your computer
back to to 'obtain an IP address automatically' in the the same window as step 3.1.
netis Wireless High Power Outdoor AP Router Quick Installation Guide

Netis WF2322 Specifications

General

5 GHz	No
2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Transmitting power	30 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	-99dBm
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Supported network protocols	PPPoE, Static IP, L2TP, PPTP, WISP, DNS, PSE
Certification	FCC, CE
Product color	White
LED indicators	LAN, Power, WLAN
International Protection (IP) code	IP55
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	2
Security algorithms	128-bit WEP, 64-bit WEP, AES, SSID, TKIP, WDS, WPA-PSK, WPA2-PSK
Antenna features	Integrated antenna
Antenna gain level (max)	10 dBi
Output current	0.5 A
Output voltage	24 V
Storage temperature (T-T)	-30 - 80 °C
Operating temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	0 - 90 %
