NEUTON CE5.2 Battery-Powered Mower - Safety & Operating Instructions 15
Step 7: Attach the Side Discharge Chute, Mulching Plug, or Rear Bagger
Side Discharge Chute
The Side Discharge Chute (Figure 12) allows for proper
discharge of the grass, which prevents clogging. The Chute
shipped without the Handle so you will have to install the
Handle prior to use using a small Phillips Screwdriver.
1. Raise the hinged Discharge Guard on the back of the
Mower (Figure 12a).
2. Orient the Discharge Chute as shown in Figure 12b.
Position the top front groove of the Chute over the
Support Rod (Figure 12a) and lower the Chute into
place (Figure 12b).
3. Lower the hinged Discharge Guard.
Mulching Plug
To mulch your grass, install the Mulching Plug.
1. If necessary, remove the Rear Bagger or Side
Discharge Chute from the Mower.
2. Install the Mulching Plug (Figure 13). Be sure to
push the Plug all the way in until the Notch in its
bottom is engaged.
There’s a slight knack to installing the Plug; push the
Plug in with a slightly arcing motion as follows:
• Align the Plug in the Mower.
• Start to push the top of the Plug in first.
• Then put pressure towards the bottom and slide in
the Plug.
Figure 12
Side Discharge Chute
Discharge Guard
Support Rod
Rear Flap
Side
Discharge
Chute
Figure 12a Figure 12b
TIP
Figure 13
Engage Notch
Discharge Guard
