TIME ON
MPCX2 SCD / DGT/ PITCH TIME (front view)
TIME OFF
HORN
CLEAR DISPLAY (blanks the SCD,
PTD, or DGT displays)
3 Programmable RESET keys
Add to or Subtract from the selected
feature / also used to select options
SET TIME
(SCD / DGT/ PTD Time and
program the 3 Reset keys)
LCD Display (16 characters x 2 lines)
Power ON / OFF Switch
OPTIONS key
Allows you to:
Set Brightness of Scoreboard
Set Auto Horn On or Off
Check Battery Level
Check Signal Strength
Link Control to Receiver Network
Select Scoreboard Model Type
MPCX2 CONTROL (rear view)
Belt Clip
Battery Compartment
Cover (2 x AA)
