INS IN / LINE OUT
These signals are on a 25-way D-sub connector.
25-way Pin Male XLR 1 Standard cable
6Line Out 1 hot25
18 Line Out 1 cold 3
19 screen 1
Male XLR 2
17 Line Out 2 hot 2 6
4Line Out 2 cold3
5 screen 1
Male XLR 3
3Line Out 3 hot27
15 Line Out 3 cold 3
16 screen 1
Male XLR 4
14 Line Out 4 hot 2 8
1Line Out 4 cold3
2 screen 1
Female XLR 1
12 Insert IN 1 hot 2 1
24 Insert IN 1 cold 3
25 screen 1
Female XLR 2
23 Insert IN 2 hot 2 2
10 Insert IN 2 cold 3
11 screen 1
Female XLR 3
9 Insert IN 3 hot 2 3
21 Insert IN 3 cold 3
22 screen 1
Female XLR 4
20 Insert IN 4 hot 2 4
7 Insert IN 4 cold 3
8 screen 1
On the AES Ins/Outs 25-way connector on the rear of the 4081, a
number '1' printed next to the corner of the connector indicates the
location of Pin 1.
