(25-way D-type SKT) Ext 2 & 5
Signal Name
Pin
Hi Lo Screen
1 EXT 2 L 24 12 25
2 EXT 2 R 10 23 11
3 EXT 2 C 21 9 22
4 EXT 2 S 7 20 8
5 EXT 2 LS 18 6 19
6 EXT 2 RS 4 17 5
7 EXT 5 L 15 3 16
8 EXT 5 R 1 14 2
(25-way D-type SKT) Ext 3 & 6
Signal Name
Pin
Hi Lo Screen
1 EXT 3 L 24 12 25
2 EXT 3 R 10 23 11
3 EXT 3 C 21 9 22
4 EXT 3 S 7 20 8
5 EXT 3 LS 18 6 19
6 EXT 3 RS 4 17 5
7 EXT 6 L 15 3 16
8 EXT 6 R 1 14 2
(25-way D-type SKT) REV 1 - 2 & DI 1 - 2
Signal Name
Pin
Hi Lo Screen
1 REV I/P 1 L 24 12 25
2 REV I/P 1 R 10 23 11
3 REV I/P 2 L 21 9 22
4 REV I/P 2 R 7 20 8
5 DI I/P 1 18 6 19
6 DI I/P 2 4 17 5
(25-way D-type SKT) Processing I/Ps
Signal Name
Pin
Hi Lo Screen
1 Mix Insert Ret L 24 12 25
2 Mix Insert Ret R 10 23 11
3 IMR Insert Ret L 21 9 22
4 IMR Insert Ret R 7 20 8
5 500 I/P L 18 6 19
6 500 I/P R 4 17 5
- 8 -
