Neve BCM10/2 MK2 - (25-Way D-Type SKT) Bus O;Ps; (25-Way D-Type SKT) LS a O;Ps; (25-Way D-Type SKT) M1, M2, SLS O;Ps; (25-Way D-Type SKT) Processing O;Ps

Console O/Ps
(25-way D-type SKT) Bus O/Ps
Signal Name
Pin
Hi Lo Screen
1 Mix O/P L 24 12 25
2 Mix O/P R 10 23 11
3 Cue O/P L 21 9 22
4 Cue O/P R 7 20 8
5 Aux O/P 1 18 6 19
6 Aux O/P 2 4 17 5
7 Aux O/P 3 15 3 16
8 Aux O/P 4 1 14 2
(25-way D-type SKT) LS A O/Ps
Signal Name
Pin
Hi Lo Screen
1 LS A O/Ps L 24 12 25
2 LS A O/Ps R 10 23 11
3 LS A O/Ps C 21 9 22
4 LS A O/Ps S 7 20 8
5 LS A O/Ps LS 18 6 19
6 LS A O/Ps RS 4 17 5
(25-way D-type SKT) M1, M2, SLS O/Ps
Signal Name
Pin
Hi Lo Screen
1 M1 LS O/Ps L 24 12 25
2 M1 LS O/Ps R 10 23 11
3 M2 LS O/Ps L 21 9 22
4 M2 LS O/Ps R 7 20 8
5 SLS O/Ps L 18 6 19
6 SLS O/Ps R 4 17 5
(25-way D-type SKT) Processing O/Ps
Signal Name
Pin
Hi Lo Screen
1 Mix O/P Ins Send L 24 12 25
2 Mix O/P Ins Send R 10 23 11
3 IMR O/P Ins Send L 21 9 22
4 IMR O/P Ins Send R 7 20 8
5 500 O/P L 18 6 19
6 500 O/P R 4 17 5
- 9 -
