New Holland 200 Series - Hydraulic Attachment Mounting Systems

6-WORKINGOPERATIONS
Hydraulicattachmentmountingsystems
Theoptionalhydrauliccouplerallowstheoperatortoremainintheoperatorseatandquicklychangetheloaderarm
attachments.
Thehydrauliccouplerswitchmustbeusedinconjunctionwiththeoneofthethreehydraulicfunctions(heldtothe
endofitsstroke):
•
Thecontrollever’sauxiliaryswitch
•
Theloaderarmdownoperation
•
Theattachmentcurl-inoperation
Tosimplifytheinstructionsonlyoneofthethreehydraulicfunctionsismentioned.
NOTE:Ifyouhaveanyquestionsaboutinstallingorremovingattachments,contactyourdealer.
Removingtheattachment
1.Positiontheattachmentabovethedismountsurface.
2.Pressandholdthehydrauliccouplerswitch(1)inthe
unlockdirection.Withtheotherhandactivateandhold
thecontrollever’sauxiliaryswitch.
3.Continuetoholdtheswitchesasyouwatchforthered
markingsontheindicatorpins(2)toappear.Visible
redmarkingsindicatethecouplerisintheunlockpo-
sition.
4.Releasethecontrollever’sauxiliaryswitchandthe
hydrauliccouplerswitch.
5.Placetheattachmentonthedismountsurface,rollthe
couplerout,andbackthemachineawayfromtheat-
tachment.
931069171
931068382
6-4
