New Holland 200 Series - Cab Door Removal and Installation

7-MAINTENANCE
Cabdoorremovalandinstallation
NOTICE:Duringtheremovalprocessretainalldoorhingeshimsandkeepinasecurelocation.Theshimsarere-
quiredforapropertwheninstallingthedooratalaterdate.
1.Opendoor.
2.Disconnectthewasherhose(1).
3.Disconnectthewireharness(2).
4.Plugthejumperconnectorintotheharness(2).
NOTE:Jumperconnectoristiedtothedoorharness.
931068951
5.Liftoffhinges(3).
RAIL13SSL0706BA2
Installation
NOTE:Ifdoorhingeshimswereremovedduringthere-
movalprocedure,installtheshims.
1.Installthedooronthehinges.
2.Installthewasherhose(1).
3.Unplugthejumperconnectorfromthewireharness
(2).
4.Connectthewireharness(2).
5.Tiethejumperconnectortothedoorharness.
931068953
7-5
