New Image FITT ROW - Final Assembly and Machine Mobility; Connecting Display and Power; How to Move the Rowing Machine

1. Pull out the extension wire (16A) from display post (67), then connect extension wire
(16A) with Display wires (15A), and put back these wires into the Display post (16A)
2. Remove the M5 Screw (13) from display (15), then fix Tablet holder (98) and display
(15) on the display post (67) with M5 Screw (13) using the Multi wrench (B)
3. Insert the adapter line (92) to power hole on the front of main frame, then plug the
adapter into an outlet.
The assembly is now complete!
Step 6
15A
15A
16A
92
98
67
13
15
16A
(13) M5 Screw 4pc
(B) Multi Wrench 1pc
To move the machine, stand behind the unit and lift up by the Rear support leg until
the transportation wheels on the Front support leg touches the ground. With the
wheels on the ground, you can transport the bike to the desired location with ease.
MOVING THE MACHINE
