EQUIPMENT
ID84 Page 5 / 20
Assembly on ID84 / ID84L
Use IDU-COUPL to assemble 2x ID84.
Use only fasteners provided (thread lock coated screws for
permanent installation).
IMPORTANT
Use VNT-BP600 and IDT-BPADAPT for stacking.
Speaker must always be installed on a horizontal surface.
Stand height and footprint must be defined to prevent assembly
from collapsing.
Ensure that audience is not allowed within a safety area which
radius is equal or higher than assembly height.
Test steadiness of the assembly by pushing in all directions.
Open the trap above IDS312.
Place ID84 on IDS312, magnet keeps it in place
IMPORTANT
Speaker must always be installed on a horizontal surface.
Stand height and footprint must be defined to prevent assembly
from collapsing.
Ensure that audience is not allowed within a safety area which
radius is equal or higher than assembly height.
Test steadiness of the assembly by pushing in all directions.
