NEXO NX242 DIGITAL TDcontroller Service manual rev100606
P.1
6
3
AWG16 (1.5mm²),600V, 105°C, Grey wire L=70mm, UL AVLV2 [for
connecting IMO connector to mains switch]
CAEDATA FDC-UL1007.16
4
Faston connector female 4.8mm isolated, UL RFWV [ fastening AWG16 on
mains switch]
CEMBRE RF-F408P
1
Cable ties 100x2.5mm VARIOUS UL ZODZ2
L0009 1
Choke, Current compensated , 18mH, 1A Schaffner - RN122-1/02
1
Fuse Temporised temporised 3.15A low break Schurter FST 0034-3125
1 Metallic contact for CN0008
Q2502-b 1 Insulator, aluminum oxide (Q2502) Regulator TO220, e=2.5mm
Bergquist - SL013AL25
R2528 1
Resistor Medium Power 2W 100 R Neohm CFR200
U2601-b U2604-b 2 Flexible insulator (with suitable insumating eyelet)
Warth K177
U2502 1 Positive Adjustable Voltage Regulator; 0°C-70°C, 2,5V-36V Texas Instrument - TL431CLP
1 Power cord 3x0.75 10/16amp straigth plug, black, 2m
Harvest electric Wire HE103 HP3
H03VV-F00075
Insulating cover, LEXAN FR700, 430um
DEGLARGES ISOLANTS
DC Fan UL GPWV2
Sunonwealth KDE1235PFB2-8
Capacitors
C1204 C1304 C1701 C1801 C1901 C2001 C2513
C2531 C2519 C1617 C1618 C1619 C1620 C1621
C1622 C1623 C1624
17 Capacitor, SMD, COG dielectric, 0805/1206 size, tol= 5%, rating 25Vmini 1 n
KEMET CxxxxC102JxGAC
C1212 C1213 C1310 C1311 4 Capacitor, SMD, COG dielectric, 0805/1206 size, tol= 1%, rating 25Vmini 1.5 n KEMET CxxxxC152FxGAC
C1629 C1630 C1631 C1632 C2507 5 Capacitor, SMD, COG dielectric, 0805/1206 size, tol= 5%, rating 25Vmini 1.5 n KEMET CxxxxC152JxGAC
C0021 C0022 C0023 C0024 C0025 C0026 C0027
C0028
8 Capacitor, Thru Hole, Miniature, rating=1000V, p=5,08mm tol 20% 1.5 n
BC components 2252 601 ..126
C1625 C1626 C1627 C1628 4 Capacitor, SMD, COG dielectric, 0805/1206 size, tol= 5%, rating 25Vmini 1.8 n KEMET CxxxxC122JxGAC
C2532 1 Capacitor, Thru Hole, ceramic low loss class 2 rating 1000V 150 p BC components 2252 601 ..116
