NEXO NX242 DIGITAL TDcontroller Service manual rev100606
P.1
7
C0011 C0012 C0013 C0014 C0015 C0016 C0017
C0018 C1414 C1415
10 Capacitor, Thru Hole, Polyester MKT Film Capacitor p=5,08mm tol 5% 2.2 n
Arcotronics R82EC1220xx5-J
C2510 C2520 2 Capacitor, Thru Hole, Polyester MKT Film Capacitor p=5mm tol 5% 100 n Arcotronics R82EC3100xx7-J
C5309 1 Capacitor, Thru Hole, Polyester MKT Film Capacitor p=5mm tol 5% 4.7 n Arcotronics R82EC1470xx5-J
C1001 C1511 C1512 C1517 C1518 C5108 C5109
C5110 C5111 C5112 C5113 C5201 C5202 C5203
C5204 C5205 C5206 C5207 C5401 C5402 C5403
C5306 C5311 C5312 C1501 C1502
29 Capacitor, SMD; X7R dielectric, 0805 size, tol= 5%, rating 100V 10 n
KEMET C0805C103J1RAC
C1205 C1206 C1207 C1208 C1209 C1210 C1305
C1306 C1307 C1308 C1407 C1408 C1427 C1428
C1637 C1638 C1706 C1707 C1708 C1709 C1806
C1807 C1906 C1907 C1908 C1909
32 Capacitor, SMD, X7R dielectric, 0805/1206 size, tol=5%, rating 50Vmini 47 n
KEMET CxxxxC473JxRAC
C1416 C1417 C1418 C1508 C1509 C1510 C1609
C1610 C1611 C1612 C1613 C1614 C1615 C1616
C5301 C5302 C5303 C5304 C5305 C2608 C2609
C2504 C5103 C5104 C5105 C5106
27 Capacitor, SMD, X7R dielectric, 1206 size, tol=5%mini, rating 50Vmini 100 n
KEMET C1206C104J5RAC
C1423 C1424 C1425 C1426 4 Capacitor, SMD; X7R dielectric, 1206 size, tolerance 5%, rating 50Vmini 220 n KEMET C1206C224J5RAC
C5310 1 Capacitor, SMD; Y5V dielectric, 1206 size, tolerance 20%, rating 25V 470 n KEMET C1206C474M3VAC
C5307 C5308 2
Capacitor, SMD, COG dielectric, 0805/1206 size, tol= 5%maxi, rating
25Vmini
22 p
KEMET CxxxxC220J2GAC
