C1705 C1805 C1905 C2005 C5101 C5102 6
Capacitor, SMD, COG dielectric, 0805/1206 size, tol= 5%maxi, rating
25Vmini
33
p
KEMET CxxxxC330J2GAC
C1515 C1516 2
Capacitor, not connected nc
C1203 C1303 C1403 C1404 C1405 C1406 C1513
C1514 C5003 C5004 C1704 C1804 C1904 C2004
C1710 C1810 C1910 C2010 C1214 C1312
20
Capacitor, SMD, COG dielectric, 0805/1206 size, tol= 5%maxi, rating
25Vmini
100 p
KEMET CxxxxC101J2RAC
C5001 C5002 2
Capacitor, SMD, COG dielectric, 0805/1206 size, tol= 5%maxi, rating
25Vmini
220 p
KEMET CxxxxC221J2GAC
C2509 C2530 C0001 C0002 C0003 C0004 6
Capacitor, SMD, COG dielectric, 0805/1206 size, tol= 5%maxi, rating
25Vmini
470 p
KEMET CxxxxC471J2GAC
C0019 C0020 2
Capacitor, electrolytic, Radial, 50V, heigth=7mm, p=2.5mm 10 u
JAMICON SSR100M1HE7 ou LELON
serie SE-SEA (en 50V)
C1211 C1309 C1401 C1402 C1633 C1634 C1635
C1636
8
Capacitor electrolytic Non Polar, 6x11, p=2.5mm, value=22UF, rating=35V 22 u Nitai ou LELON serie RN -RNG marcon
C1409 C1410 C1411 C1412 C1413 C1429 C1430
C1505 C1506 C1507 C1601 C1602 C1603 C1604
C1605 C1606 C1607 C1608 C1639 C1640
20
Capacitor, electrolytic, Radial, 50V, heigth=?mm, p=?mm 22 u
ELGEN MI840022u-50V (JAMICON
SSR220M1VE7 ou LELON serie SE-
SEA (en 50V))
C1702 C1703 C1802 C1803 C1902 C1903 C2002
C2003
8
Capacitor electrolytic Non Polar, 13x25, p=5mm, value=470uF rating=35V
(Nitai Case F)
470 u Nitai ou LELON serie RN -RNG
C1201 C1202 C1301 C1302 4
Capacitor, electrolytic, Radial, 105°C, Very Low Impedance 470UF 25V
(RVI136) d=10mm p=5mm
470 u BC components 2222 13636471
C1419 C1420 C1421 C1422 4
Capacitor, Thru Hole, Electrolytic, Axial, 85°C, tolerance 20%, 10x18, rating
10V
1000 u BC components 2222 02134102
1
Capacitors NON CONNECTED
Connectors
CN5002 CN5003 2
2.54mm x 2.54mm Box Header 3X2 contacts [link main board - RS232
board]
E-TEC SLS-006-S920-11
2 Female connector 2.54mm 3x2 contacts [goes into CN5002 CN5003]
E-TEC IDS-006-S100-01/P
