NEXO NX242 DIGITAL TDcontroller Service manual rev100606
P.1
9
1
Round Conductor Flat cable .050", 28AWG stranded, halogen free
insulation, UL94V-0 (6cond), 80°C
any UL AVLV2
CN5501 1 DIP plug 2.54mm 7X2 for LCD screen ribbon cable
E-TEC IDP-014-S100-00
1
Round Conductor Flat cable .050", 28AWG stranded, halogen free
insulation, UL94V-0 (14cond)
3M 2010serie
1 HE10 Transition for LCD ribbon E-TEC IDS-014-S100-01/P
CN5001 1 .100" x .100" pin strip header 2X28 (no standard pin 1 identification) KONTEK_intercomHE14_254
CN5201 1
2mm x 2mm pin strip header 2X7 (no standard pin 1 identification) for Xilinx
Jtag
HARWIN_2mmPitch
CN5301 1
.100" x .100" pin strip header 2X6 (no standard pin 1 identification) for DSP
Jtag
KONTEK_intercomHE14_254
CN0001 1
Sense Connector male
Wago231-468/001-000
CN5004 1 SUB-D9 Connector, PCB mounting, Turned solder pins, straight
HARTING 09 67 009 5654
CN0002 CN0003 2
XLR female receptacle NEUTRIK NC3FBH2
CN0004 CN0005 CN0006 CN0007 4
XLR male receptacle NEUTRIK NC3MBH
1
Sense Connector female WAGO 231-108/026-000
Discrete
L0001 L0002 L0003 L0004 L0005 L0006 L0007
L0008
8 Choke, EMI suppression, ferrirte core, AXIAL, 27uH, 10% EPCOS B78108-T1273-K
D1207 D1208 D1209 D1307 D1308 D1309 D1401
D1402 D1403 D1404 D1405 D1406 D1407 D1408
14 Diode Small signal Philips BAS85
D0001 D0002 D0003 D0004 D0005 D0006 D0007
D0008 D1201 D1202 D2510 D2511 D1301 D1302
14 Diode Small signal, high speed Philips PMLL4148
D0009 D0010 D0011 D0012 D0013 D0014 D0015
D0016
8 Diode, TRANSIL, bidirectional, 18V SGS-THOMSON SM6T18CA
D5001 D5002 2 Diode, TRISIL, bidirectional, 25V, 100A, Low capacitance SM6T33CA
D0017 D0018 2 Diode, TRANSIL, unidirectional, 27V SGS-THOMSON SM6T27A
D1409 D1410 2 Diode, Voltage regulator 3.3V Philips BZV55C3V3
