NXAMPMK2 USER MANUAL PAGE 37 / 80
The name of the subscribed transmitter(s) can be checked into the Dante
TM
On the below picture, we can see for example that the NXAMPmk2 with the Dante -
NEXO-NXAMP4x4mk2-
TM
device
-
TM
Virtual Soundcard software).
NB: The NXDT104mk2 can subscribe up to four different channels from four different Dante
TM
transmitters.
The digital audio status for the NXAMPmk2 is declared OK if all digital input channels E/F/G/H are
declared OK, otherwise all analog inputs are un-muted.
A digital input itself is declared OK if connected to nothing (aka. not patched) or patched with a
subscription and an audio stream valid, otherwise if the stream is failing or the subscription is unresolved
the input is declared faulty.
- When used with NXAE104. Detection of a valid digital audio stream on AES/EBU is based on the clock
locking information. If there is digital signal on the AES/EBU input, and the clock detected is within the
accepted clock range, the receiver clocks itself o
The digital audio status for the NXAMPmk2 is declared OK if all digital input channels E/F (XLR1) and
G/H (XLR2) are declared OK, else all analog inputs are un-muted.
you are using E/F inputs only and the Analog Fallback, please link E/F input to G/H input with a small
XLR cable.
- When used with NXES104. The Ethersound
TM
network should be in star configuration for the Analog
Fallback to work properly. It does not work in daisy chain configuration (except for simple network like
one mixer to one receiver). It does not work with ASIO input either.
The detection is based on a valid EthersoundTM stream on the IN port of the NXES104. If a valid
EthersoundTM stream is detected, the analog inputs will be muted, else they will be unmuted.
MONITORING
See monitoring menu section to learn more about Monitoring sub menus.
SETTINGS
See settings menu section to learn more about Settings sub menus.
