Nexo Ray Sub Series User Manual

INTRODUCTION Page 3/58
With RAY SUB patent pending technology, NEXO is again moving one step forward. RAY
SUB technology is about optimizing positioning and phase relationship of radiating
surfaces in vented enclosures, so that acoustic distance from rear to front sections
always increases as frequency decreases; consequently, rear and front section always
sum up efficiently – typically 5 dB gain from rear section in the forward direction – and
cancel in the rearward direction.
Used as a single cabinet, RAY SUB Technology allows the same cabinet to be configured
for any polar pattern, omnidirectional as a standard direct radiating subwoofer when
speakers are facing the audience, or highly directional when cabinet is rotated speakers
sideways or upwards.
Used in arrays, RAY SUB subwoofers can be set back to back, front to front, in vertical
columns, and beam-steered upwards or downwards provided column length is sufficient.
NEXO RAY SUB technology brings a never achieved low frequency directional control to
the sound reinforcement industry, raising one more time NEXO standards.

Nexo Ray Sub Series Specifications

General

Brand	Nexo
Model	Ray Sub Series
Category	Subwoofer
Language	English
