INSTALLATION
1. Insert memory card (Class 6 or higher) in to the iN-CAR CAM, taking care to follow correct
orientation markings (gold contacts facing the back of the device). Push the memory card until it
clicks into place.
Do not remove or insert the memory card when the iN-CAR CAM is powered on, this may
damage the memory card.
Note:
- Use the edge of a small coin (or similar object) to push the memory card in place if required, a
second push inwards will release the memory card.-
2. Attach the iN-CAR CAM to the supplied windscreen mount, taking care the locking tab has
‘clicked’ firmly into place and plug the aerial cable connector into the socket marked GPS.
3. Remove the protective plastic film from the suction pad. Select suitable position for the mount and
clean windscreen with a dry / clean cloth to achieve good contact between the glass and mount,
while pushing the suction cup onto the glass turn the locking wheel clockwise to secure the mount
to the windscreen, ensure placement of the GPS mount is such that the GPS aerial is not
obstructed by the roof of the vehicle.
Please ensure that once mounted the iN-CAR CAM lens is located within the area of the vehicles
windscreen wipers to maintain a clear view during rainfall.
4. Connect the supplied car adaptor to mini-USB socket of the iN-CAR CAM and then plug the
car adaptor into the 12-24Vdc outlet of your vehicle. The device will automatically power on and
start recording once power is available.
In some vehicles this will be when connection is made, for others the device will power on once
the ignition has been turned on.
Note:
- Do NOT wire the iN-CAR CAM directly to a 12V supply or damage will result.
- Always use the supplied car adaptor cable to supply 5Vdc to the iN-CAR CAM.
08
12-24V DC
The above diagram is for illustration purposes only.
