CAMERA - PARTS & CONTROLS
Please see below to identify the parts and controls of your Dash Cam.
Left side:
1. Side cover
There are two types of side cover supplied:
Standard covers:
These are fitted when the Dash Cam as standard and are used during normal operation.
Remember to replace the side cover before use.
Locking covers:
Included within the Security Pack are two locking covers, these can be secured to the Dash
Cam using the supplied anti-tamper screws. This allows the owner of the vehicle to prevent
un-authorised access to or operation of the Dash Cam.
2. Anti-tamper screw insert
Insert thread for the anti-tamper screw.
3. Reset button
In the unlikely event the Dash Cam becomes unresponsive, press the RESET button to
restart the Dash Cam.
1
2
3
Reset
4 65
13
