PARTS & CONTROLS (CONTD.)
Back:
11. Speaker
Integral speaker for audio playback directly from the Dash Cam.
12. Suction Cups
Used to attach the Dash Cam to the vehicles existing rear-view mirror.
13. Reset button
In the unlikely event the Dash Cam becomes unresponsive, press the RESET button to
restart the Dash Cam.
14. MicroSD Card slot
Insert the MicroSD card here, taking care that the gold contacts are facing towards the LCD
screen side of the Dash Cam. Push the memory card until it clicks into place.
15. Microphone
Integral microphone for audio recording.
16. Strap Retaining Hooks
Attach the silicon straps here to secure the Dash Cam to the vehicles existing rear-view
mirror, if required.
Note:
- The hooks and covers can be removed by simply sliding the cover in the direction
of the arrow.
17. DC-IN & USB socket
Connect the supplied car power cable or USB data cable here.
18. Camera lens
Wide Angle 140°, 6 Element glass lens for optimum picture quality.
11
17
18
12
15
13
14
16
10
