NextBase SDV37-SD - BATTERY AND CONNECTOR DETAILS; Battery Pack Components; External Power Output Jack

PARTSANDFUNCTIONS
Namesofbatterypartsandtheirfunctions
Batteryknob
DCINconnector
BatteryindicatorLED
Playerterminals
Fixpole
DCOUT(Non-standardjack)
Connectthepoweradaptertorecharge(AC/DCadapter).
Supplypowertotheplayer.
Donotshort-circuittheterminals.
CAUTION:
Whenthebatteryisdischarging,LEDisoff.
Whenrechargingthebattery,LEDisred.
WhentheLEDturnsfromREDtooff,meansfinishingrecharge.
1 2
3
456
Fixthebatterytotheplayerwheninstallingbattery.
OutputDC7.4/7.2V.EspeciallyforsupplyingpowertoTVTuner
Box(Optionalaccessory).
Twistittotighten/detachthebatterypack.
ENG21
