3.3 Basic operation
WF1943B
3-11
Initialized settings：
Initialized settings are indicated in the table.
Settings related to output on/off, output on/off at power on, arbitrary waveform, setting memory, user units ,
remote control, GPIB address, GPIB delimiter, and USB ID are not initialized.
Initialization table
Key operation Menu Initial settings Remarks
MODE NORMAL
TYPE BURST
SOURCE EXT (1 ms, at INT) When TYPE=TRIG, GATE,T-GATE
DELAY 0.3 µs When TYPE=TRIG
MARK 1.0 When TYPE=BURST, TRIG
SPACE 1.0 When TYPE=BURST
MODE→BURST
STOP-LEVEL OFF (0%, at ON).
TYPE FREQ
SOURCE EXT (1 ms at INT) When MODE=SINGLE, GATED
MODE SINGLE
FUNCTION LIN
TIME 1 s
MODE→SWEEP
STOP-LEVEL OFF (0%, at ON). When MODE=GATED
START 1000 Hz
STOP 10000 Hz
CENTER 5500 Hz
MODE → SWEEP,
TYPE=FREQ
SPAN 9000 Hz
START −90 deg
STOP 90 deg
CENTER 0 deg
MODE → SWEEP,
TYPE=PHASE
SPAN 180 deg
TYPE FM
FREQUENCY 100 Hz
MODE→MODU
FUNCTION
MODE → MODU,
TYPE=FM
DEVIATION 1000 Hz
MODE → MODU,
TYPE=PM
DEVIATION 90 deg
ENTRY→FREQ 1000 Hz
ENTRY→AMPTD 0.1 Vp-p
ENTRY→OFFSET 0 V
ENTRY→PHASE 0 deg
Continued next page
