3.3 Basic operation
WF1943B
3-22
 Operation tree
OUTPUT
ON/OFF
Output on/off
MODE
Oscillation mode
NORMAL
/
BURST
/
SWEEP
/
MODU
/
NOISE
/
DC
BURST
Menu
TYPE (Burst type) [BURST/TRIG/GATE/T-GATE]
SOURCE (Trigger/gate source selection)
DELAY (Trigger delay) * For TYPE: TRIG
MARK (Number of times signal present) * For TYPE: BURST/TRIG
SPACE (Number of times signal not present) * For TYPE: BURST
STOP-LEVEL (Stop level)
BURST
Operation
MAN TRIG
SWEEP
Menu
TYPE (Sweep target) [FREQ/PHASE]
SOURCE (Trigger source selection) * For MODE: SINGLE/GATED
MODE (Sweep mode) [SINGLE/CONT/GATED]
FUNCTION (Sweep waveform) [LIN/LOG,
/ / /SIN]
START (Sweep start value)
STOP (Sweep end value)
TIME (Sweep time)
STOP-LEVEL (Stop level) * For MODE: GATED
CENTER (Sweep center value)
SPAN (Sweep width)
START-STATE (Start state)
STOP-STATE (Stop state)
SWEEP
Operation
START
/
STOP
/
PAUSE
