4.2 Sweep
4-20 WF1943B
• FUNCTION determines the sweep type.
: For example,
provides step-type change of output (e.g., frequency) at the sweep time halfway
point. LIN/LOG provides linear or logarithmic variation of the output with respect to the time axis.
i
i
i
i
SIN ( )
LIN
LOG
LIN
LOG
LIN
LOG
• Internal sweep trigger source
: The trigger signal is generated at the following rate, then sweep is conducted.
However, the trigger interval is 100 ms even if set to less.
ＩＮＴ
１００．０ｍｓ
Ｆ－ＳＷＰ：ＴＹＰＥ ＳＯＵＲＣＥ ＭＯＤＥ
4
• START-STATE and STOP-STATE : Respectively set the output to start and stop values.
Since the sweep synchronization output becomes the
respective start and stop states, the state of external equipment
can be checked. The Start-State is the same as pressing the
STOP
key (during single sweep).
Relationship between sweep values and sweep synchronization
output,
“4.2 Sweep (■Sweep value and SYNC OUT)”, cf.
• To generate the trigger signal via remote control (GPIB or USB), set the GET command or TRG
command from the remote control interface.
For details of the remote control command,
“Remote Control Instruction Manual”, cf.
Trigger rate
