NFL 2 MINUTE DRILL - Section Diagram; Game Section Identification

6
Front Section
Conveyer base
Section
Upper Rear
Section
Control Panel
Section Diagram
The game is manufactured in three sections. Here is a diagram with the sections la-
beled for identification during assembly.
3052 Black hole plug 8
6001B Allen wrench 3/16” 1
6105 Latch Tool 1
6110 Joint connector 1/4-20
Thread
20
6212 1/4 x 3/4 Flat washer black 20
CG2027 Power cord 9’ 10” 1
FB9001 Service Manual 1
PC60601 1/4-20 x 5/8 BHCS (black) 12
PC60601A Allen wrench 5/32” 1
PC60622 1/4-20 x 1 BSHCS BLK 6
6281 1/4-20 x 1 1/2 BSHCS 2
Ice Part Description Qty
Programming Insert 1
Assembly insert 1
Schematic insert 1
Spares package includes the following:
