NFL 2 MINUTE DRILL - Maintenance: Display Boards; Display Board Locations

7
ICE part numbers
[1] CB2232X
[2] CB2233X
[3] FB2032X
[4] FB2033X
[5] FB2035RX
[6] FB2035WX
[7] FB2035BX
[8] DA2133X
Display Board locations
Control panel display boards are located below. FB2032X is a display that includes
six display boards and five mini footballs. See picture below.
Maintenance
1
1
1
3
START
2
5
6
7
4
8
8
8
8
