NGTeco NG-RV2100 - Product Overview

Product Overview
1.Top view
2.Side View
3.Bottom View
4
Reset WiFi
· Press two buttons simultaneously and
hold it for 3s.
Recharge Key/Pause
· Short press to Start/Pause recharging.
ON/OFF/Clean/Pause
· Press and hold it for 3s to turn on/off the
machine.
· Short press to Start/Pause cleaning.
· Under abnormal circumstances, press
and hold it for 15s to force the shutdown.
Charging Contact
Universal Wheel
Left Driving Wheel
Rolling Brush
Rolling Brush
Cover Buckle
Battery Cover
Left Side Brush
Right Driving Wheel
Right Side Brush
Laser Ranging Sensor
Anti-collision Sensor
Left Recharge Sensor
Linear Laser Sensor
Recharge
Sensor
Linear Laser W
all S
ensor
System Reset Key
Dust Box
Dustbin Push Button
