Single-Ended Connections
+
–
AI+
AI–
V
oltage
Source
NI 9215 with
Screw/Spring
T
er
minal
COM
Connect the ground signal to COM to keep the signal source
within the common-mode voltage range.
NI 9215 Getting Started Guide
|
© National Instr
uments
|
21
20
22
