NI 9215
with BNC
AI+
AI–
+
–
Voltage
Source
The NI 9215 with BNC has internal circuitry that maintains the
common mode voltage range.
Connection Guidelines
• Make sure that devices you connect to the NI 9215 are
compatible with the module specifications.
• You must use 2-wire ferrules to create a secure connection
when connecting more than one wire to a single terminal on
the NI 9215 with screw terminal or NI 9215 with spring
terminal.
22 | ni.com | NI 9215 Getting Started Guide
