NI RTI-12309 - Page 7

Table 3 : Mapping St
andard Signals to Generic Element Names
Generic Element
Name (in Bank x)
Generic Single-
Ended (Digital or
Analog
)
Generic Dierential
(Digit
al or Analog)
Other Signal Types
IO x.A x.0 x.0+
Contact NI for more information about
st
andard pinouts.
IO x.B x.1 x.0-
IO x.C x.2 x.1+
IO x.D x.3 x.1-
IO x.E x.4 x.2+
IO x.F x.5 x.2-
IO x.G x.6 x.3+
IO x.H x.7 x.3-
© National Instruments Corporation 7
RTI-12309 Getting Started
