Allmänt
Denna serviceinstruktion beskriver byte av inverterkort
(PWB2) i AMS 10-8 / F2040-8.
KORT- OCH KABEL-KIT
AMS 10-8 / F2040-8
718 499PWB 2 och drossel med kablage
KOMPONENTPLACERING
ELKOMPONENTER
KontrollkortPWB1
InverterkortPWB2
FilterkortPWB3
Anslutningsplint, inkommande matning och kom-
munikation mot kort AA23
TB
DrosselRA1
Beteckningar i komponentplacering enligt standard IEC 81346-2.
AMS 10-8 / F2040-8
LEK
PWB2
PWB1
PWB3
TB
RA1
| SE4
