Accessories
Active cooling 4-pipe
Address (dipswitch setting): 1101 0100
When cooling is permitted the following applies:
Current menus
Menu Name
Factory
setting
1.9.5 min. temp. cooling flow 10 °C
cooling flow temp. at +20°C 3 °C
cooling flow temp. at +40°C 6 °C
time betw. switch heat/cool 2 hrs
use room sensor None
heat at room under temp. 1,0
cool at room over temp. 1,0
4.9.2 start cooling 25 °C
stop heating 17 °C
stop additional heat 5 °C
filtering time 24 hrs
Connections, accessory card
Input Function
X2:23-24 block cooling
Input Function
K1 Circulation pump cooling (GP13)
K2 Mixing valve (QN18), close
K3 Mixing valve (QN18), open
K4 Reversing valve (QN12)
Mixing valve controlled additional heat (AXC 40)
Address (dipswitch setting): 1010 0000
• DM calculated on BT25.
• Additional heat signal is given when GM ≤ starts
additional heat.
• The shunt valve controls to maintain calculated
temp on BT25.
• The shunt valve controls the number of whole
seconds as the difference (calculated supply
temperature BT25 supply temperature sensor) *
shunt valve amplification. The shunt valve opens
for even numbers and closes for odd numbers.
• The mixing valve is stationary during the waiting
period.
• The mixing valve closes if DM > start compressor.
• At start up the shunt valve closes for 120 secs.
Section 4 | Description of functions
