27
11.6 - Display
ESC: Exit the DISPLAY menu.
Info: Displays the manufacturer name, product name/model, software versions, and serial
number.
Clock: Displays the calendar date and time in the real time clock. Pressing and holding the
“OK” button for 5 seconds enables the date and time settings to be updated manually.
Main Volt: Displays the gate operator main control voltage in volts DC.
Battery Volt: Displays the gate operator backup battery voltage in volts DC.
Sun Volt: Displays the solar panel input voltage in volts DC.
Motor Volt: Displays the voltage at the motor in volts DC.
UL Volt: Displays the voltage at the UL/Edge sensor input in volts DC.
Temperature: Displays the temperature of the gate controller board in degrees Centigrade or
Fahrenheit (press OK and hold 5 seconds to change scale).
Service: The following information is recorded and viewable about the operating history of the
gate:
Total: Displays the total number of open-close cycles (non- Settings ).
Partial: Display the total number of partial cycles. Reset by pressing the “OK” button for sev-
eral seconds.
Maint. Display the number of cycles before service is required. Settings from 1000 to 50000
cycles in increments of 1000 cycles.
Motor: Displays the Motor position, voltage, and current.
Motor 1: Displays the Motor1 position, voltage, and current.
Motor 2: Displays the Motor2 position, voltage, and current.
Charger: Displays the battery charger voltage and current.
Last Reset: Displays the code for diagnostic review. Used for diagnostic and troubleshooting.
ESC: Exit the DISPLAY menu.
12 - GLOSSARY
CLASS I - RESIDENTIAL VEHICULAR GATE OPERATOR- A vehicular gate operator (or system) intended for
use in a home of one-to four single family dwelling, or garage or parking area associated therewith.
CLASS II - COMMERCIAL / GENERAL ACCESS VEHICULAR GATE OPERATOR - A vehicular gate operator
(or system) intended for use in a commercial locaon or building such as a mul-family housing unit (ve
or more single family units), hotels, garages, retail store, or other building servicing the general public.
CLASS III - INDUSTRIAL / LIMITED ACCESS VEHICULAR GATE OPERATOR - A vehicular gate operator (or
system) intended for use in an industrial locaon or building such as a factory or loading dock area or
other locaons not intended to service the general public.
